噴粉面自干五金油墨

本產品主要用于各種金屬、玻璃、真空電鍍、水電鍍、電泳、陽極氧化鋁、電解板、鋁塑板、噴塑、噴粉、靜電噴漆面、烤漆面以及各種天花吊頂氧化板、鏡面板、覆膜板、輥涂板、尼龍加玻纖、三聚氰胺板,UV表面,木板烤漆面等等制品的絲印及移印。
2、產品特性：亮光、附著力佳、快干、耐沖壓。
3、稀釋劑：用我司B-03專用稀釋劑或783開油，用718洗網水清洗網版。
4、固化劑：單組份使用，也可選擇添加我司JS-10專用固化劑用于增加油墨附著力及物理化學抗性。
5、油墨調配方法：開罐先攪拌均勻，取所需量油墨稀釋到合適印刷粘度。如需添加固化劑，先加固化劑攪拌后靜置10分鐘，待油墨與固化劑完全交聯后再進行稀釋。
6、干燥時間：常溫干燥，表干時間5-10分鐘，實干時間在24小時以內，80℃烘烤20分鐘可快速干燥。
7、添加固化劑后的使用時限：4-6小時，過期請棄用，剩余油墨不可回收。

性能檢測
1、3M膠帶劃百格測試：無脫落
2、耐沖壓測試：1mm厚鋁板180°折彎無變化。
3、耐酒精測試：用脫脂棉沾濃度99%工業酒精以500G力水平來回200次無脫色。

注意事項
1、先小量試印確認符合要求后再批量生產。
2、做好承印物的表面清除油脂及雜質工作，以促進附著效果。
3、附著力、硬度、耐酸性、耐酒精性、耐化學品性、抗劃傷性、耐磨性等性能的檢測，
需要完全固化后方可檢測。
4、未經允許情況下，不得將本系列油墨與其它類型油墨混用及配色。
5、油墨，稀釋劑使用及儲存時嚴禁煙火。
6、使用時注意施工場所的通風狀況良好，盡量避免皮膚直接接觸。
7、本品不慎濺入口、鼻、眼、耳內，應用大量水清洗或直接求助醫生。
8、技術參考數見下表：
   檢驗項目 檢驗結果 測試條件
   油墨線度 ≤12um 刮板細度計
   干膜光澤 ≥65° 60°鏡面光澤計
   干燥速度 表干 25℃×5-10min 或60℃×2-3min
   實干 25℃12Hr或60℃×10min
   耐酒精性 無變化 500克力/cm2酒精棉200次來回
   附著力 100/100 1mm×1mm×100格3M膠紙剝離
   耐酸性 無變化 浸泡5HCI×24Hr
   耐堿性 無變化 浸泡5NaOH×24Hr
   耐鹽性 無變化 浸泡5NaCI×24Hr
   耐水性 無變化 浸泡20℃自來水×96Hr
   耐磨性 不見底 500克/cm2負載含砂橡皮200來回
   耐熱性 無變化 80℃×12Hr
 The products are mainly used in screen printing and the printing of various kinds of metal, glass, vacuum plating, electroplating, electrophoresis, water anodic alumina, electrolytic plate, aluminum plate, plastic spraying, dusting, electrostatic spray painting, paint surface and various ceiling oxide board, mirror panels, coated board, roller coated board and other products.
2, product characteristics: light, good adhesion, fast drying, stamping resistance.
3, diluent: with our B-03 special thinner or 783 open oil, washing network water cleaning screen with 718.
4, curing agent: one component use, can also choose to add our JS-10 special curing agent is used to increase the ink adhesion and physical and chemical resistance.
5, printing ink allocation methods: open cans to stir well, take appropriate amount needed to dilute ink printing viscosity. If you need to add curing agent, first add curing agent after mixing and set aside for 10 minutes, and curing agent for ink completely crosslinking after dilution.
6, the drying time: dry, dry time table for 5-10 minutes, work time within 24 hours, 80 degrees bake for 20 minutes can be dried quickly.
7, adding curing agent after the use of time: 4-6 hours, expired please abandoned, residual ink Unrecyclable.
[detection] performance
1, 3M tape row adhesion test:  without shedding
2, stamping resistance test: 1mm thick aluminum 180 degree bend without change.
3, alcohol resistant test: with cotton dipped in 99% alcohol concentration of industry to 500G stress level and back 200 times without decolorization.
[note]
1, the first small try printing again after confirmation of compliance with the requirements of mass production.
2, do a good job in the substrate surface to remove grease and impurities, in order to promote the adhesion effect.
Detection of 3, adhesion, hardness, acid resistance, alcohol resistance, chemical resistance, scratch resistance, abrasion resistance and other properties,
Fully cured before detection.
4, without permission, may not use the series of ink and other types of ink mixing and matching.
5, ink, fireworks is strictly prohibited the use of thinner and storage.
6, the use of ventilation conditions attention the construction site is good, try to avoid direct contact with skin.
7, this product is inadvertently splashed entrance, nose, eyes, ears, use a large number of water washing or direct help doctor.
